Type ZX

The ZX bedder has an extra stirrer at the top of the bucket. Therefore this machine can process products that are more susceptible to clogging.

The ZX bedder has an extra stirrer at the top of the bucket. Therefore this machine can process products that are more susceptible to clogging. The hydraulic motors have flexible couplings and the chain guard can be easily opened for maintenance. The ZX can process sawdust, crushed straw, chopped straw, dry compost and green bedding (if it has not been ensiled), which makes it a versatile spreader.

Read more ∨

Interested in Type ZX?

We are happy to help you

Visit us Make an appointment Call us +31 (0)85-068 56 13 Send us an email info@flingk.nl
Description Specifications Technical Specifications Options Downloads

Description

The ZX bedder has an extra stirrer at the top of the bucket. Therefore this machine can process products that are more susceptible to clogging. The hydraulic motors have flexible couplings and the chain guard can be easily opened for maintenance. The ZX can process sawdust, crushed straw, chopped straw, dry compost and green bedding (if it has not been ensiled), which makes it a versatile spreader.

Specifications

Type Minimum required oil capacity Maximum oil capacity LxWxH (cm) Volume (L) Weight empty (kg) Max. load weight (kg)
ZX 750 25 L/ min 175 bar 60 L/min 225 bar 131x143x131 750 330 500
ZX 1000 30 L/ min 175 bar 60 L/min 225 bar 139x143x138 1000 350 775
ZX 1200 30 L/min 175 bar 60 L/min 225 bar 139x163x138 1200 390 850
ZX 1500 35 L/min 175 bar 60 L/min225 bar 150x183x148 1500 450 975

Technical Specifications

Type ZX

• Discharges to the left and to the right
• Hardox blade and wear strip
• One double acting hydraulic function required
• Hydraulic motors with flexible couplings and relief valve
• Manually adjustable metering valves
• Big metering roll at the bottom of the bucket
• Conveyor with sealed edges and scraper
• Rubber covered drive- and second roller
• 2-layer powder coating

Options

Foldable sweeping brush on the left or on the right side
one extra double-acting hydraulic function needed
Flow and pressure limiter
required when driving machine exceeds the hydraulic pressure and flow

Downloads
