Cable Digger

Preventing cable damage
Too often cables or wires are hit during digging. Flingk Machinebouw has the solution to prevent substanti-al loss: the Cable Digger! This machine enables you to dig with minimal chance of damaging the cables. Thanks to the compact construction the bucket hardly juts out.
The machine fits in a trench so digging deep is no problem.

How does it work?
The Flingk Cable Digger has a brush which rotates at high speed. The brush removes the sand, which is collected in the bucket.
Any stones are effortlessly removed as well. The Cable Digger can also be used as a standard bucket.
The bucket has a hydraulic adjustable plate so you can alternate between digging and brushing.
The valve is also needed to empty the bucket after brushing material.
The advanced hydraulic system automatically controls the ground pressure so the brush digs regularly wit-hout bumping. Overload is prevented so the brush works optimally. You can dig straight down at facades and in combination with a rotator it is also possible to dig on the side of the excavator.

Read more ∨

Description

Preventing cable damage
Too often cables or wires are hit during digging. Flingk Machinebouw has the solution to prevent substanti-al loss: the Cable Digger! This machine enables you to dig with minimal chance of damaging the cables. Thanks to the compact construction the bucket hardly juts out.
The machine fits in a trench so digging deep is no problem.

How does it work?
The Flingk Cable Digger has a brush which rotates at high speed. The brush removes the sand, which is collected in the bucket.
Any stones are effortlessly removed as well. The Cable Digger can also be used as a standard bucket.
The bucket has a hydraulic adjustable plate so you can alternate between digging and brushing.
The valve is also needed to empty the bucket after brushing material.
The advanced hydraulic system automatically controls the ground pressure so the brush digs regularly wit-hout bumping. Overload is prevented so the brush works optimally. You can dig straight down at facades and in combination with a rotator it is also possible to dig on the side of the excavator.

Specifications

Type LxWxH folded (cm) LxWxH unfolded (cm) Weight (kg) Minimum required oil capacity Maximum oil capacity
BV 2400 550x12655x2500 550x3300x745 242 20 l/min 50 l/min
BV 2400 550x12655x2500 550x3300x745 242 20 l/min 50 l/min
BV 2400 550x12655x2500 550x3300x745 242 20 l/min 50 l/min

Options

PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
PersFilter
Aanbevolen, standaard op SVV, HD, filtert de olie om de ventielen te beschermen
